LZ Alerts

Expires: Dec 31, 2024Hazard

Charlotte Clark Jun 03, 2021 6:57pm

Carilion Roanoke Memorial Hospital (CRMH)

Alert Issued: June 3, 2021
Alert Expires: December 31, 2024

Situation: Starting Wednesday, June 16, 2021, there will be a tower crane on the Campus of Roanoke Memorial Hospital. The tower crane will be the first of two tower cranes that will be on site for construction activities over the next several years for the Crystal Springs Tower addition to Carilion Roanoke Memorial Hospital.

Background: The tower cranes will be used for construction activities at the site of the future expansion. The project site is adjacent to the South Tower of Carilion Roanoke Memorial Hospital which is the site of the rooftop helipad.

Assessment: The first tower crane will be placed the on June 16th and 17th with operations set to start on June 21, 2021. The center of the tower crane will be approximately 348.5 feet from the edge of the helipad. The jib tip radius will be 266.6 feet; therefore, the tip of the jib will be approximately 82 feet from the helipad. The height of the tower crane will be 260 feet at the tower peak or apex. This will be approximately 80 feet higher than the rooftop helipad. A 75-foot crane will be used on June 16th and 17th to set the tower crane in position.
The center of the second tower crane will be approximately 247.2 feet from the helipad. The jib tip radius will be 171.1 feet; therefore, the tip of the job will be approximately 76 feet from the edge of the helipad. The height of the tower crane will be 210.9 feet at the tower peak or apex. This will be approximately 31 feet higher than the rooftop helipad. It will not be set until February 2022.
When the tower cranes are not in use, they will be weathervaning (free slewing mode).
Recommendation: All aircraft utilizing the Carilion Roanoke Memorial Hospital rooftop helipad are asked to exercise caution on approach and departure.
Please contact our Communication Center at 155.385 pl 118.80 for any updates. The Communications Center may also be contacted at (888) 377-7628. The Communications Center may also be contacted at (888) 377-7628.
For additional questions please contact Charlotte Clark, Safety Officer at (540) 892-3395.

General Information
LZ Type: Hospital
Coordinates:
(All the same)
N 37° 15' 06" x W 79° 56' 34"
37° 15.1' x -79° 56.57'
37.25164400 x -79.94282800
Picture(s):
FAA Nav ID: VG62
Address: 1906 Belleview Avenue SW
Roanoke, VA 24014
Phone: (540) 981-7000
Comments: Contact CRMH for medical reports at:
RX: 155.385 TX: 155.385 PL: 118.8
Group Specific Info
Group Nav ID:
Comments:
Hospital Information
Capabilities
Trauma Level: 1 Pediatrics: Y
Cardiac: Y Burn Center: N
Stroke: Y HR OB/Gyn: Y
Security
Security Phone: (540) 981-7911
Security Contact: Ed Watkins
Radio Frequency:
Emergency Department
ED Contact: Wren Brendel
ED Phone: (540)981-7000
Record Information
Last Update: Apr 07, 2021 4:11pm Charlotte Clark
Added By: Aug 04, 2010 2:50am Gene Jones
Weather Stations
Loading from AviationWeather.gov
LZ Information
Location/Description: Ground pad 2 blocks west of hospital next to hangar along railroad tracks. Lights and windsock. Wires along railroad tracks. Roof top pad elevation 1000�.
Hazards: Construction site near ED entrance.
Approach/Departure: Construction site near ED entrance.
AWOS:
Nearest Fuel
Name Dist Bearing IFR
Lynchburg Regional Airport 35.8 116° ESE N
AWOS/ASOS: 434-239-0025
Nearest Specialty Centers
Name Dist Bearing Trauma Burn Ped Neuro
Carilion New River Valley Medical Center 28.7 116° ESE 3 N N Y
Comm Chan: RX: 155.385 TX: 155.385 PL: 118.8
Dimensions: 80 feet diameter
Surface: Heated helipad
Elevation: 1000 feet
Jet A Fuel: No
Nav Freq:
Max Weight: 14,000
Windsock: Yes
Lighting: Yes
Instrument App: No
Alternate LZ Information
Heliport ID: VG47
Coordinates: N 37° 15' 00" x E 79° 57' 00"
37° 15.' x 79° 57.'
37.25000000 x 79.95000000
Location/Description: Ground pad 2 blocks west of hospital next to hangar along railroad tracks. Lights and windsock. Wires along railroad tracks. Ground Pad Dimensions: 132 ft x 87 ft
